MaxPac XL

The MaxPac® 8250 XL is the most advanced, most powerful, and most feature-rich Rugged Portable Workstation available on the market today; its single, dual, or triple 23" screen/s with full HD 3D display/s has never before been provided on any computer system, portable or otherwise. The MaxPac 8250 XL is specifically designed for stereo imagery exploitation, where massive storage (16 TB expandable to 48 TB), massive computing power (dual E5-2600 Xeon 6 Core processors), massive memory (up to 512 GB of DDR3 ECC memory), and the latest nVidia Kepler (GeForce GTX 670 and 680) graphics technology can satisfy the extreme requirements of the most demanding applications. Add to this the extended temperature range of 0 to 50°C, dust filtration, an option for integrated UPS (Uninterruptable Power System) and external 28 VDC support, and a totally modular and serviceable design. The result is the ultimate computer platform for imagery exploitation and analysis, designed from the ground up to be placed in forward positions without benefit of conditioned power and conditioned air.

Dual Intel® Xeon® E5-2600 Processors, Supermicro X9DAi motherboard

16x240 pin DIMM slots DDR3 1600MHz ECC which supoort up to 128GB unbuffered memory(RDIMM) or 512GB of registered memory(UDIMM)

Single,Dual, or Triple 23” 1920x1080

250mcd/m2 Brightness, Viewing Angle: 2D 170/160, 3D 80/12; Contrast Ratio: DFC 5000000:1(1000:1) Response Time: 5ms;75Hz Resonse Time;16.7 million colors

Choice of nVidia Quadro 2000 or 4000 or GeForce GTX 670

Dual 1GBit Ethernet, 2 Internal Firewire 1394, 7.1 HD Audio, 8 USB 2.0 external, 2 USB 2.0 Headers plus 2 USB 2.0 internal

3x PCI-E3.0 x16 Slots, 2x PCI-E 3.0 x8 Slots, 1x PCI-E 3.0 x4 Slot(in x8 slot).

(requires both CPUs for access to all PCI-E slots)

HDPac4™ magazine allows removal of all drives without tools in less than 10 seconds. Individual drives are also replaceable without removing the entire HDPac4.

4 x 3.5" Removable drives up to 3TB HD or 600 GB

2x SATA 3.0 Ports, 8x SATA 2.0 Ports(in two groups of 4)

Unused external video port for projector open on single and triple display configurations. Dual display configuratons will require a second video card for video projector support.

850 Watt 90-264VAC 50/60Hz 115VAC@400Hz, Optional integrated UPS with support for external 28VDC

0-50°C operating temperature; 10-90% relative humidity non-condensing; exceeds Mil Std 810F Hot Operating Temperature cycle test; -20 to 70°C non operating

FCC Class A, CE

Custom Explorer water-tight roller case stores Keyboard, mouse and cords

38 lbs. without HD magazine or accessory roller pack - 44lbs with HD magazine 54 lbs. with accessory roller pack

75 lbs. accessory roller case and HD magazine 68 lbs. without HD magazine (ADD 5 lbs. for UPS option)
